Cable Railing

AdvantageLumber.com offers the highest quality Cable Railing
cable railing

Cable Railing

Create an Unobstructed View with Sophisticated Cable Railing

DeckWise® WiseRail™

Heritage Series Kits

A budget-friendly cable railing for any type of wood post as an outside-to-outside fitting on a straight level run or on a pitch or stairs. The tensioning device is a 2 7/8″ long threaded stud which installs on the back side of one end post. A pull-lock fitting is installed through the other end.

This through-the-post configuration is the only scenario in which the economical threaded stud kits may be used. The threaded stud kits are even more economical than the WiseCable™ Heritage WC-HS Series, but the threaded studs are a basic, functional fitting, not a hide-in-the-post solution. A brass hex nut and some metal thread (both covered by an end cap) will extend beyond the back of the post on one end. A pull-lock fitting is installed through the other end.

Use the WiseCable™ Heritage WC-HS Series for decks with dedicated end posts for each run where the posts are situated such that, the back sides of the posts are all accessible. Meaning you can use a through-the-post configuration. This is both the most economical solution and where the fittings are least visible.

When taking the WiseCable™ Heritage WC-HS Series cable railing through a corner, do not bend the cable past 45° at any one time. If turning 90°, a 2-step turn using a double corner post configuration is required

WiseCable™ Heritage Series: 5′ Kit

$22.13

WiseCable™ Heritage Series: 10′ Kit

$24.68

WiseCable™ Heritage Series: 15′ Kit

$27.22

WiseCable™ Heritage Series: 20′ Kit

$29.77

WiseCable™ Heritage Series: 25′ Kit

$32.33

WiseCable™ Heritage Series: 30′ Kit

$38.09

WiseCable™ Heritage Series: 40′ Kit

$43.18

WiseCable™ Heritage Series: 50′ Kit

$48.27

Estate Series Kits

Use the WiseCable™ Estate WC-ES Series for any type of wood post as an outside to outside fitting on a straight level run or on a pitch or stairs. The tensioning device is a 3 1/2″ long Invisiware Receiver, which installs through the wood post on one end. A pull-lock fitting is installed through the other end.

Use the WiseCable™ Estate WC-ES Series for decks with dedicated end posts for each run where the posts are situated such that, the back sides of the posts are all accessible. Meaning you can use a through-the-post configuration. This is both the most economical solution and where the fittings are least visible.

When taking the WiseCable™ Estate WC-ES Series cable railing through a corner, do not bend the cable past 45° at any one time. If turning 90°, a 2-step turn using a double corner post configuration is required.

WiseCable™ Estate Series: 5′ Kit

$38.88

WiseCable™ Estate Series: 10′ Kit

$43.21

WiseCable™ Estate Series: 15′ Kit

$47.55

WiseCable™ Estate Series: 20′ Kit

$51.77

WiseCable™ Estate Series: 25′ Kit

$56.06

WiseCable™ Estate Series: 30′ Kit

$62.28

WiseCable™ Estate Series: 40′ Kit

$68.50

WiseCable™ Estate Series: 50′ Kit

$77.54

Legacy Series Kits

Use the WiseCable™ Legacy WC-LS Series for any type of wood post. The tensioning device is an Adjust-a-Body with threaded eye, which attaches via a mounting screw to the lag eye, threaded tab. A push-lock with threaded eye attaches the same way to the other end.

The WiseCable™ Legacy WC-LS Series can be used to go up a stair and across a landing by inserting post protector tubes (order CS-TUBE separately) in the break-over post. The tube will prevent the cable from carving a groove into your post where it exits at an angle.

WiseCable™ Legacy Series: 5′ Kit

$60.97

WiseCable™ Legacy Series: 10′ Kit

$64.34

WiseCable™ Legacy Series: 15′ Kit

$67.72

WiseCable™ Legacy Series: 20′ Kit

$71.10

WiseCable™ Legacy Series: 25′ Kit

$78.94

WiseCable™ Legacy Series: 30′ Kit

$85.01

WiseCable™ Legacy Series: 40′ Kit

$95.00

WiseCable™ Legacy Series: 50′ Kit

$104.34

Legacy Series Stair Kits

Top posts are often corner posts, which may require the stair run to connect to the face of the post. The top and bottom of the cable run would be connected perpendicular to those posts, and only the intermediate posts would be drilled on the angle for the cable to run through.

Use the WiseCable™ Legacy WC-LSS Series for any type of wood post as an inside to inside fitting on a pitch or stair application. The tensioning device is an Adjust-a-Body with threaded eye, which attaches via a mounting screw to the lag eye, threaded tab. A push-lock with threaded eye attaches the same way to the other end.

The WiseCable™ Legacy WC-LSS Series can be used to go up a stair and across a landing by inserting post protector tubes (order CS-TUBE separately) in the break-over post. The tube will prevent the cable from carving a groove into your post where it exits at an angle.

WiseCable™ Legacy Series Stairs: 5′ Kit

$69.25

WiseCable™ Legacy Series Stairs: 10′ Kit

$71.34

WiseCable™ Legacy Series Stairs: 15′ Kit

$73.43

WiseCable™ Legacy Series Stairs: 20′ Kit

$76.76

Tools and Accessories

42″ Anodized Aluminum Cable Brace with 13 Holes

3/4″ x 3/4″ tube, 42″ long for cutting down to any size rail height. Holes pre-drilled at 3 1/8″ on center, 13 holes total. For use between structural posts to keep cables code-compliant on level runs. Use cable brace plugs to attach to top and bottom rail or deck. Comes with 2 plugs and screws.
$29.98

42″ Anodized Aluminum Cable Brace Undrilled

3/4″ x 3/4″ tube, 42″ long for cutting down to any size rail height. Comes undrilled so slots can be field drilled to match cable array. Comes with 2 stair plugs and screws.
$24.98

Cable Gripping Pliers

Locking pliers with machined jaws to grip the cable as you are tensioning the cable. Keeps the cable from turning and prevents damage to the cable when cable is being tensioned.
$149.98

Cable Release Key

For 1/8″ push- and pull-locks only. Releases cable from push-lock and pull-lock type fittings before cables are tensioned.
$4.98

Cut-Off Tool

Used to cut cable flush with the end of pull-lock fittings and to cut excess threads off stud-type tensioners. Includes mandrel and two cut-off wheels.
$24.98

Light Duty Hanger Bolt Driver

Use to install Adjust-A-Body with hanger bolt tensioners. Makes driving hanger bolts fast and easy.
$39.98

Heavy Duty Cable Cutters

Heavy-duty cable rail cutters for burr-free cutting. Hardened heat-treated blades cut 1/8″ cable cleanly.
$159.98

Light Duty Cable Cutters

Light-duty cable rail cutters for burr-free cutting. Hardened blades cut 1/8″ cable cleanly.
$39.98

Post Protector Tube, 4 Pack

The post protector tube is inserted into a wood post where the cable enters/exits the post at an angle to keep the cable from biting into the wood. Pack of 4.
$4.98
> All Prices Are Subject To Change Without Notice <

To Order Advantage Cable Railing:
Call 1-877-232-3915 or 1-877-232-3915

Cable Railing Installation Diagram

cable railing installation
CABLE RAILING INSTALLATION INSTRUCTIONS (pdf)
